YOUR SOURCE

FOR PRE-ENGINEERED STEEL BUILDINGS

WESTERN HAS YOU COVERED

"PBR" Panel

The versatility of this exposed fastener panel makes PBR a classic choice. Recognized for versatility in multiple environments, the PBR metal panel is a staple, providing various designs through horizontal and vertical options as well as roof and wall applications. PBR offers high quality with the ease of delivery and installation.

_PBR-Panel-Icon

COLOR CHART -COLORS MAY VARY

Sample-Color-Chart-WS

"PBR" Architect/Engineer Information

1. “PBR” panel is a structural roof and wall panel. This panel can be installed directly over purlins or joists. Several different UL 90 construction numbers are available for this panel.
2. “PBR” panel is recommended for Z\x:12 or greater roof slopes.
3. Field applied sealant is required at panel sidelaps and endlaps.
4. “PBR” panel is a through-fastened panel.
5. The information in this manual is believed to be correct and accurate. It should not be used for any specific application without being reviewed by a registered professional engineer.

GENERAL DESSCRIPTION
---Coverage Width - 36”
---Minimum Slope - Z\x:12
---Panel Substrate - Galvalume® Gauge - 26 standard - 29, 24 and 22 also available

"PBU" Architect/Engineer Information

1. “PBU” panel is a structural roof and wall panel. This panel can be installed directly over purlins or joists. “PBU” panel is UL 90 rated per construction number 39.
2. “PBU” panel is recommended for 1:12 or greater roof slopes.
3. Field applied sealant is required at panel sidelaps and endlaps.
4. “PBU” panel is a through-fastened panel.
5. The information in this manual is believed to be correct and accurate. It should not be used for any
specific application without being reviewed by a registered professional engineer.

GENERAL DESCRIPTION
Coverage Width - 36”
Minimum Slope - 1:12
Panel Substrate - Galvalume® Gauge - 26 standard - 29, 24 and 22 also available

PBU-Panel-Icon

"PBU" Panel

Our most versatile pro le, this exposed fastener panel can be installed vertically or horizontally. Offering various design options, the PBU metal panel can be used in both roof and wall applications as well as installed horizontally or vertically. As one of the most cost-efficient metal panels in the industry, PBU sustains with longevity and quality.

COLOR CHART -COLORS MAY VARY

Sample-Color-Chart-WS

"PBC" Panel

Versatile in roof and wall applications, this exposed fastener panel is ideal for any industry. The PBC metal panel endures with longevity as the highest quality metal in the industry. Providing stability with the ease of installation, PBC is popular for structures with numerous uses and functions.

PBC-Panel-Icon

COLOR CHART -COLORS MAY VARY

Sample-Color-Chart-WS

"PBC" Architect/Engineer Information

1. “PBC” panel is a structural roof and wall panel. This panel can be installed directly over purlins or joists. Several different UL 90 construction numbers are available for this panel.
2. “PBC” panel is recommended for 3:12 or greater roof slopes.
3. Field applied sealant is required at panel sidelaps and endlaps.
4. “PBC” panel is a through-fastened panel.
5. The information in this manual is believed to be correct and accurate. It should not be used for any
specific application without being reviewed by a registered professional engineer.

GENERAL DESCRIPTION
Coverage Width - 32”
Minimum Slope - 3:12
Panel Substrate - Galvalume® Gauge - 26 standard - 29, 24 and 22 also available

WESTERN STEEL BUILDINGS PRODUCTS CONTAIN UP TO 90% RECYCLED STEEL,

making our prefabricated steel buildings not only more economical than a conventional building, but also good for the environment.
